Gentec-EO UP19K-50L-W5-D0 Thermal Detector

Updated:2025-03-13

Brand: Gentec-EO
Model: UP19K-50L-W5-D0
Description: Gentec-EO UP19K-50L-W5-D0 Thermal detector for laser power measurement up to 50 W.
Data download

Feedback
WeChat

QQ

Online Service

Product Details

Gentec-EO UP19K-50L-W5-D0 Thermal Detector Description：

Datasheet(CN) Datasheet(EN) PC-Gentec-EO User's Manual BLU User's Manual INTEGRA User's Manual UP and XLP12 User's Manual

Gentec-EO UP19K-50L-W5-D0 Thermal detector for laser power measurement up to 50 W.

Measure extremely high average power density lasers with the W absorber

The W absorber can handle tightly focused beams thanks to its extremely high average power density damage threshold of 100 kW/cm2. It measures from UV to IR but is not suitable for CO2 laser wavelengths.

Ideal for UV lasers and tightly focused beams

Very low risk of damaging the equipment

Faster measurement with XNR Anticipation

Measure laser power up to 10x faster (model-dependant) with XNR AnticipationTM. Our proprietary algorithm looks at the rate at which the signal increases or decreases and combines this with calibration data to predict the result. The measurement is therefore calculated and displayed faster than the natural response of the detector.

Save several seconds to tens of seconds for each measurement

Shorter operation interruption

Faster laser output diagnostics

Increased productivity

No compromise on measurement accuracy

Optional INTEGRA (USB or RS-232) output

When you choose the INTEGRA output option you get an all-in-one measurement instrument that combines both the detector and the meter in one convenient product. Plug the detector in your PC, install our free software and start measuring.

The most cost-efficient solution

Same measurement performance as our other solutions

No compromise on interface functions and features

Compact solution for OEM applications and field servicing

Save money on recalibration with an all-in-one instrument

Key Features

Modular Concept

Increase the power capability of your detector: 5 different cooling modules

Very High Damage Threshold

100 kW/cm2 in average power density

Compact Design

Only 21 mm thick (15S model)

Energy Mode

Measure single shot energy up to 200 J

Smart Interface

Containing all the calibration data

Specifications

Measurement capabilities
Maximum average power (continuous)	50 W
Maximum average power (1 minute)	85 W
Noise equivalent power	1 mW
Spectral range	0.193 - 10 μm
Typical rise time	1.4 s
Power calibration uncertainty	±2.5 %
Repeatability	±0.5 %
Measurement capabilities (Energy mode)
Maximum measurable energy	200 J
Noise equivalent energy	0.02 J
Minimum repetition period	5 s
Maximum pulse width	133 ms
Energy calibration uncertainty	±5 %
Damage thresholds
Maximum average power density	100 kW/cm2
Maximum energy density	1.1 J/cm2
1. At 1064 nm, 10 W CW. May vary with wavelength and average power. 2. At 1064 nm, 7 ns, 10 Hz. May vary with wavelength and pulse width.
Physical characteristics
Cooling	Convection (heatsink)
Aperture diameter	19 mm
Absorber	W
Dimensions	76.2H x 76.2W x 73.6D mm
Weight	0.48 kg
